DG 300 HD ACD
COMPACT, DURABLE AND SAFE SOLUTION WITH ADVANCED FILTRATION CERTIFIED ATEX
The ACD Series for combustible dust is designed to ensure high durability and easy maintenance in ordinary environments. Made of painted steel, this industrial unit offers an optimized footprint and can be easily moved thanks to forklift entry. It is equipped with an M-class antistatic filter and a HEPA H14 absolute filter, both featuring an automatic cleaning system.
ADVANTAGES
- The system includes a side channel blower, which is a silent, powerful three-phase motor which requires no maintenance
- Easy and safe to maintain
- Compliant with EN 17348: DRY TYPE
- ATEX certified filter cleaning system
DATASHEET
Index | Unit | DG300 ACD |
---|---|---|
Power | kW | 20 - 25 |
Electrical protection | IP | 65 |
Max water lift | mmH₂O | 3.100 - 4.400 |
Max air flow | m³/h | 1.100 - 2.050 |
Suction inlet | mm | 120 |
Noise level (EN ISO 3744) | dB(A) | 78 |
Use zone | Ordinary location | |
Atex zones | ACD | |
Filter Type | Star | |
Cleaning system | Automatic AUT | |
Capacity | l | 220 |
Dimensions | cm | 95x180x220h |
Weight | kg | 810 |
![]() |
